Laser Module Rotating Waveplate

Compact Piezo Laser Modules

The Rotating Polarizer module is a wavelength specific, vertical or horizontal polarization rotation device for OEM applications and will provide polarization rotation from +/- 90°.



Specifications

  • 32.55 Beam Height

  • Single or Dual Wavelengths

    • 1064, 532, 355, 266

    • 1064/532, 532/355, 532/266

  • Shutter, Electronically Controller

  • USB or RS232

  • Can be Daisy-Chained

  • Compact

  • 41mm x 41m x 25mm

  • Damage Threshold: 5 J/cm2

  • Movement (tact time): ≤ 500ms, full range of motion

  • Aperture Dia: 8mm

  • Transmission, single wavelength: ≥ 99%

  • Transmission, dual wavelength:

    • 1064nm ≥ 98%, 532nm ≥ 98%

    • 532nm ≥ 98%, 355nm ≥ 98%

    • 532nm ≥ 98%, 266nm ≥ 98%

  • Range: ± 90 degrees

  • Accuracy: ± 0.2 degrees

  • Resolution: ≤ 0.1 degrees



Service Features
  • Demo Units Available
  • Warranty: Full 2 Year Warranty
  • Service: Integration Assistance, Full Customer Support.
QUICK SPEC MATCH:

 USB or RS-232 Controlled

 Dual or Single Wavelength

 Rotate Polarization +/- 90 Degrees

Tact Time: ≤ 500s, full range of motion

*Customization & OEM Available
DOWNLOAD DATA:
Datasheet Coming Soon!
